The 'wheel of augmentation' machine
Does the augmentation wheel aid motion? A twin-drum machine driven by a worm
A single heading across the top asks whether the 'wheel of augmentation' aids the movements or not (text 1). The large drawing that fills the sheet shows a machine with two great parallel drum-wheels on a common horizontal shaft, driven through a worm-and-pinion gear and mounted on a boxed base. Faint show-through and further sketches lie behind the main figure but are not part of the transcription.
On this page
Does the wheel of augmentation aid motion?
The heading poses the question directly: whether the 'wheel of augmentation' is of use to the movements or not. It frames the twin-drum machine below as a test of whether the added wheel helps or hinders.
Twin-drum machine driven by a worm and pinion
Two large drum-wheels turn side by side on one horizontal axle, geared through a worm-screw and pinion at their center. The whole rests on a solid boxed base, with the shaft projecting to a threaded terminal at the right.
